Tower Shape Springs

Tower Shaped Springs (alias Truncated Cone Scroll Shape Springs), because of its special shape, is often called: pagoda shaped spring, bamboo shaped spring. Due to the complex design and many production supporting links, the truncated cone scroll shaped spring has strict requirements, so few domestic spring companies are willing to get involved in this field.Be-Cu truncated cone scroll springs are widely used in occasions with small space and large loads and shock absorption devices, such as playing the role of buffer in the elevator industry.There are three common types of truncated cone scroll springs:

Equal helix angle truncated cone scroll spring;
Equal pitch truncated cone scroll spring;
Equal stress truncated cone scroll spring.

Due to the complex process of the truncated cone scroll spring, we can produce it according to your drawings, or design the truncated cone scroll spring to meet your needs.

The Specification Of Frustum Scroll Spring

Name	Code	Name	Code	Name	Code
pitch	t	Inner diameter	d	Helix angle	a
Minimum medium radius	R1	free height	Ho	Material thickness	t(a)
maximum middle radius	R2	Deformation	f	Material width	B(b)
total circle	n1	work circle	n	board clearance	g

The Case Studies Of Tower Pagoda Shaped Springs

Currently, our non-standard Tower Pagoda Shaped Springs are exported to America, Canada, Australia, United Kingdom, Germany, France, Sout Africa, and many other countries all over the world. We are ISO9001-2015 registered and also certified by SGS.

Our custom tower pagoda shaped springs fabrication service provides durable and affordable springs that meet your specifications for automotive, medical, aerospace, electronics, food, construction, security, marine, and more industries. Fast to send your inquiry or submit your drawings to get a free quote in the shortest time.Contact us or Email [email protected] to see how our people, equipment and tooling can bring the best quality for the best price for your custom tower pagoda shaped springs project.
